Holley Holley Tunnel Ram Carburetor - 0-9776
$599.95
Skip to product information
The 0-9776 450 CFM mechanical secondary carburetor is designed as a universal performance carburetor for use on tunnel ram applications.
Holley Holley Tunnel Ram Carburetor - 0-9776
$599.95
Features:
- Universal Holley 4-Barrel Carburetor
- Mechanical secondaries
- Specifically designed for tunnel ram intakes
- Gold dichromate finish resists corrosion
Product Specifications:
- Product Details: 450 CFM - 4160 - Mechanical Secondaries - Gold Dichromate - Gasoline
- Adjustable Air Bleeds: No
- Adjustable Emulsion Bleeds: No
- Adjustable Idle Feed Restrictors: No
- Air Cleaner Flange Diameter: 5-1/8
- Barrel Quantity: 4
- Barrels: 4
- Barrels Quantity: 4
- Body Color: Gold Dichromate
- Body Finish: Plated
- Body Material: Aluminum
- Booster: Straight
- Booster Design: Straight
- Carburetor Material: Aluminium
- Carburetor Use: Street
- CFM: 450
- CFM Rating: 450
- Choke: None
- Choke Type: None
- Circuit Count: 2
- Color: Gold Dichromate
- Condition: New
- Cubic Feet Per Minute Rating: 450
- Finish: Gold Dichromate
- Flange Shape: Square
- Flange Size: Square bore
- Flange Type: Square/4150
- Float Level: Externally Adjustable
- Fuel: Gasoline
- Fuel Inlet: Single
- Fuel Inlet Count: Single
- Fuel Inlet Type: 9/16-24
- Fuel Type: Gasoline
- Gasket Or Seal Included: Yes
- Grade Type: Tunnel Ram
- Linkage Attached: Yes
- Marine Approved: No
- Marine Use: No
- Material: Aluminum
- Meter Block Material: Cast Aluminum
- Metering Block Color: Gold Dichromate
- Model: 4160
- Mounting Hardware Included: No
- Mounting Hole Quantity: 4
- Part Type: Carburetor
- Primary Float Type: Side Hung Nitrophyl
- Primary Jet Diameter: 58
- Primary Main Jet Size: 58
- Primary Power Valve: 8.5
- Primary Pump Nozzle Size: 31
- Primary Throttle Bore Diameter: 1.5
- Primary Venturii Diameter: 1.093
- Product Type: Carburetor
- Secondaries: Mechanical
- Secondary Barrel Type: Mechanical
- Secondary Float Type: Side Hung Nitrophyl
- Secondary Jet Extensions: No
- Secondary Throttle Bore Diameter: 1.5
- Series: Classic Performance
- Spacer Included: No
- Supercharged Application: No
- Throttle Bore Diameter: 1.5
- Throttle Kickdown Provision(S): Compatible with GM, Chrysler, and Ford A/T kickdown linkage
- Vacuum Ports: 1 timed (spark) port
Installation Notes:
Notice - Due to the natural color variations of the dichromate plating process, the plating color may vary from casting to casting (within a carburetor) and from carburetor to carburetor. This is considered normal and is not a cosmetic defect. If you desire a carburetor with no color variation, please shop our black and shiny finish carburetors.
